This Concept Map, created with IHMC CmapTools, has information related to: Node_19_Precheck_to_Change_over_to_Scoop_Sea-water_Circulation, Electrical Power Diesel Generator On Load, Boilers Boiler 1 Pressure, Checks to be done Required Scenario Condenser, Simulator to Parallel the Turbo Alternator When Running Checks to be done, Deaerator Full with guage glass reading Between 60~70 mm, Checks to be done Required Scenario Electrical Power, Pressure About 6 Mpa Running on HFO supply, Boilers Boiler 2 Pressure, Electrical Power Turbo Generator 2 Off, Checks to be done Required Scenario Deaerator, Tanks Atmospheric Drain Tank (ADT) About 60% full, Electrical Power Emergency Generator Auto, Stand-by, Checks to be done Required Scenario Tanks, Electrical Power Turbo Generator 1 On Load, Tanks Distilled Water Tank (DWT) About 60% full, Electrical Power Shore Power Off, Condenser Condenser Vacuum Satisfactory and Cooling on, Checks to be done Required Scenario Boilers
