This Concept Map, created with IHMC CmapTools, has information related to: Node_06a_Precheck to Put the Economizer On-line, Boilers Boiler 2 Low Fire, Tanks Distilled Water Tank (DWT) About 60% full, Electrical Power Diesel Generator On, Tanks Atmospheric Drain Tank (ADT) About 60% full, Deaerator Full with guage glass reading Between 60~70 mm, Checks to be done Required Scenario Electrical Power, Boilers Boiler 1 Low Fire, Checks to be done Required Scenario Tanks, Simulator to Parallel the Turbo Alternator When Running Checks to be done, Electrical Power Turbo Generator 2 Off, Electrical Power Shore Power Off, Low Fire Pressure about 6 Mpa Running on DO supply, Checks to be done Required Scenario Deaerator, Electrical Power Turbo Generator 1 Off, Electrical Power Emergency Generator Auto, Stand-by, Checks to be done Required Scenario Boilers
