This Concept Map, created with IHMC CmapTools, has information related to: Node_20_Precheck to Run the Simulator to Start Distiller, Tanks Atmospheric Drain Tank (ADT) About 60% full, Checks to be done Required Scenario Boilers, Pressure About 6 Mpa Running on HFO supply, Electrical Power Shore Power Off, Electrical Power Emergency Generator Auto, Stand-by, Electrical Power Turbo Generator 2 Off, Electrical Power Turbo Generator 1 On Load, Condenser Condenser Vacuum Satisfactory and Cooling on, Checks to be done Required Scenario Condenser, Simulator to Start Distiller Checks to be done, Boilers Boiler 1 Pressure, Tanks Distilled Water Tank (DWT) About 60% full, Checks to be done Required Scenario Electrical Power, Checks to be done Required Scenario Tanks, Deaerator Full with guage glass reading Between 60~70 mm, Boilers Boiler 2 Pressure, Electrical Power Diesel Generator On Load, Checks to be done Required Scenario Deaerator
